Product Description
Product Name
Human Body Temperature Measurement Face Recognition Access Control System
Purpose It can be applied to gate channel and access control attendence to achieve safe and efficient access control of personnel. Recognition system can reduce face to face contcat between people,reduce attendence of manul inspections, protect against high fever groups and ensure people’s safety.
Applicable Scene : School,community,airport,subway,bus,office building and so on.
Advantage : Fiscal recognition, High temperature alarm,Access Control
Technology :Human Face Recognition Technology & Infrared Thermal Imaging Module.
Supports :Face recognition with wearing mask, Password verification, Card (Optional)
Operating System :Industrial-grade Linux intelligent operating system
Processor (Regular) :Four Core 1.2G
Processor Local Storage :Run memory 4GBit DDR3, storage capacity 32GBit Screen
5.0 inch capacitive touch screen,Touchscreen virtual keys,All metal body, Rain proof, Dustproof
Pixel
854 * 480
Camera White Balance
Auto
Storage capacity
Faces: 3,000;Record: 1 million
Communication method
USB,TCP/IP,WIFI
Attendance report
U disk export the temperature record details and attendance statistics report; Computer software collects data through network
connected devices
Language : English,
Rejection rate (frr) <=0.1% False acceptance rate (far) <=0.0001% Recognition mode : 1: 1, 1: N Matching speed : 0.2 Seconds Dynamic face recognition distance : 0.5-1.5 meters Name display and built-in bell Support : Professional access control functions Tamper alarm, door open alarm, forced door open alarm, alarm linkage and output, a group of door open signals, time zone authority control, personnel authority control, holiday authority control, external access control read head, Wiegand 26/34 input Working voltage and current : 12V / 1A Human body temperature detection : Support Temperature detection distance : 0.5~0.6 meter Measuring Accurecy : ± 0.3°C Adaptable working temperature range of the equipment : -20°C~65°C Thermal imaging temperature range : -40°C~85°C Nomal Mode : Register the face firstly, Identify the face & measure the temperature, the nomal one will pass in,and alarm for the abnomal one (exceeds the standard) ,used in places where people are fixed. Stranger Mode : No need face registration, just face temperature measurement, alarm if exceeding the standard, used in places where people are not fixed. Other Mode : The temperature measurement function can be turned off after the epidemic period, which can be used for dynamic face access control attendance Weight : Gross weight 1490 g ，Net weight 896 g Equipment size : 210*88*26mm
